Home > products > Corrugated Pipe Extrusion Line > HDPE PVC DWC Pipe Manufacturing Machine 40mm-1200mm High Speed

HDPE PVC DWC Pipe Manufacturing Machine 40mm-1200mm High Speed

Name: HDPE PVC DWC Pipe Manufacturing Machine 40mm-1200mm High Speed
Brand: Qingdao Sincere Machinery Co., Ltd
SKU: SMDWC110,SMDWC300,SMDWC600
Price: 110.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Sincere

Model Number: SMDWC110,SMDWC300,SMDWC600

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD 20,000-200,000

Delivery Time: 7-15 work days

Payment Terms: L/C,T/T

Supply Ability: 20 Sets Per Month

Get Best Price

Chat Now

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                PVC DWC Pipe Manufacturing Machine, HDPE DWC Pipe Manufacturing Machine, 1200mm Corrugated Pipe Extrusion Line


Driven Type:	Electric	Feeding Mode:	One Feed
Screw Speed:	22 Rpm	Structure:	Horizontal
Pipe Od:	40-1200mm	Moulds Material:	Aluminium Alloy
Mould Material:	Aluminium Alloy	Main Electrics:	Siemens / Schneider/ABB Etc

Driven Type:	Electric
Feeding Mode:	One Feed
Screw Speed:	22 Rpm
Structure:	Horizontal
Pipe Od:	40-1200mm
Moulds Material:	Aluminium Alloy
Mould Material:	Aluminium Alloy
Main Electrics:	Siemens / Schneider/ABB Etc

Product Description

HDPE PVC DWC Pipe Manufacturing Machine 40mm-1200mm High Speed

Key Specifications

Driven Type	Electric
Feeding Mode	One Feed
Screw Speed	22 Rpm
Structure	Horizontal
Pipe OD	40-1200mm
Moulds Material	Aluminium Alloy
Main Electrics	Siemens / Schneider/ABB Etc

Product Overview

PLC Control Electrical HDPE PVC DWC Corrugated Pipe Extrusion Line Manufacturing Machine designed for high-speed production of PE PP double wall corrugated pipes (40-1200mm). This advanced machine incorporates foreign technology and patented innovations for superior performance.

Key Features

High-performance single-screw extruder ensures stable output
Horizontal structure forming machine with shuttle drive and sealed water-cooling
Vacuum forming platform maintains optimal cooling temperature
Independent detachable modules reduce mold change time
PLC touch screen control for easy operation
Online flaring capability and high automation level

Production Specifications

Specification	OD50	OD63	OD75	OD90	OD110	OD125
Speed (m/min)	8.0-11.0	7.5-9	8.0-9.5	7.0-8.5	5.5-6.0	4.5-6.0

Note: Production speed may fluctuate ±10% due to raw materials and environmental factors. Double-walled pipe production speed is 10-20% lower than single-walled.

Applications

Road Surface Engineering

Railway, city road, and highway drainpipes

Mining Engineering

Transport of ore, river silt, coal ash, mine air supply, ventilation, and drainage pipes

Communication Engineering

Protective casing for communication cables, optical cables, and power cable protection

Frequently Asked Questions

What is the brand name of the corrugated pipe extrusion line?

The brand name is Sincere.

What models are available?

SMDWC110, SMDWC300, and SMDWC600 models.

Where is it manufactured?

Manufactured in China.

What is the minimum order quantity?

Minimum order is 1 set.

What is the delivery time?

50 working days.

What are the payment terms?

30% in advance, 70% after testing before shipment.

What is the monthly production capacity?

20 sets per month.
