PPR PERT Stainless Steel Pipe Insulation Machine Insulated Pipe Extrusion Machine

Name: PPR PERT Stainless Steel Pipe Insulation Machine Insulated Pipe Extrusion Machine
Brand: Qingdao Sincere Machinery Co., Ltd
SKU: SMPI005,SMPI550
Price: 110.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Sincere

Model Number: SMPI005,SMPI550

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD 20,000-200,000

Delivery Time: 7-15 work days

Payment Terms: L/C,T/T

Get Best Price

Chat Now

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                Stainless Steel Pipe Insulation Machine, PPR PERT Pipe Insulation Machine, Insulated Pipe Extrusion Machine


Control System:	PLC Touch Screen	Pipe Length:	6m
Application:	Steel Pipe Insulation	Pipe Structure:	PE+PU+Steel Pipe
Material:	Polyurethane	Insulation Thickness:	20-50mm
Pipe Diameter:	20-100mm	Production Speed:	10-15m/min

Control System:	PLC Touch Screen
Pipe Length:	6m
Application:	Steel Pipe Insulation
Pipe Structure:	PE+PU+Steel Pipe
Material:	Polyurethane
Insulation Thickness:	20-50mm
Pipe Diameter:	20-100mm
Production Speed:	10-15m/min

Product Description

PPR PERT Stainless Steel Pipe Insulation Machine Insulated Pipe Extrusion Machine

Key Specifications

Attribute	Value
Control System	PLC Touch Screen
Pipe Length	6m
Application	Steel Pipe Insulation
Pipe Structure	PE+PU+Steel Pipe
Material	Polyurethane
Insulation Thickness	20-50mm
Pipe Diameter	20-100mm
Production Speed	10-15m/min

Product Overview

Fully Automatic Polyurethane Insulation Pipe Production Machine with PLC Touch Screen Control. This PERT II thermal insulation pipe extrusion production line features one-step double-plastic PPR composite insulation pipe production technology.

High-quality PPR inner tube (PN=2.0Mpa) ensures reliable hot water pipe connections

PVC/PE hard outer casing provides excellent protection during transport and installation

Polyurethane foam insulation layer tightly adheres to both tubes for superior thermal performance

Implements the "plastic replaces steel" plan for modern heating systems

Technical Specifications

Steel Tube Size (mm)	Casing Wall Thickness (mm)	Insulating Layer (mm)
45	2.0	29
57	2.0	29
76	2.2	30
89	2.2	30
108	2.4	30
133	2.4	30
159	2.5	40
219	2.5	40
273	3.0	40
325	3.0	40
377	3.5	40
426	4	50

Applications

Indoor water supply, hot water, and purified water pipe insulation

Liquid food pipeline insulation in food industry

Solar water heater systems and central air-conditioning piping

Ground radiant heating systems

Electroplating, petroleum, and chemical plant transmission systems

Machine Components

The complete production line includes extruders, extrusion coating head, vacuum calibrating cooling tanks, automatic correcting device, tractor, cutting machine, stacker/winder, and polyurethane foaming machine.

Shipping Information

The machine is packaged in sturdy wooden crates for safe transportation. Shipping is handled via reliable freight carriers with tracking information provided upon dispatch.

Frequently Asked Questions

Q: What is the brand name of the insulation pipe machine?

A: The brand name is Sincere.

Q: What are the model numbers?

A: Model numbers are SMPI005 and SMPI550.

Q: Where is the machine made?

A: The machine is manufactured in China.

Q: Can it produce different pipe sizes?

A: Yes, the machine can produce various pipe sizes.

Q: Is the machine easy to operate?

A: Yes, it's designed for user-friendly operation.
