Length 3000mm PVC Sheet Welding Machine Hdpe Welding Bending Machine

Name: Length 3000mm PVC Sheet Welding Machine Hdpe Welding Bending Machine
Brand: Qingdao Sincere Machinery Co., Ltd
SKU: SMH-3000，4000，5000
Price: 110.00 USD
Availability: InStock

Product Details

Brand Name: Sincere

Certification: CE

Model Number: SMH-3000，4000，5000

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD 20,000-200,000

Delivery Time: 15 Working Days

Supply Ability: 20 Stes Per Month

Get Best Price

Chat Now

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                3000mm PVC Sheet Welding Machine, PVC Welding Bending Machine, Hdpe Welding Bending Machine


Heating Power:	9kw-15kw	Air Pressure(Kg.F /Cm2):	6.0-8.0
Bending Length:	2000-6000mm	Warranty Time:	One Year
Sheet Thickness:	3.0-30.0mm	Rated VoltageRated Voltage:	380V50/60Hz
Processing Period:	20 Days	Specification:	Sheet Width 600, 900, 1200, 1500, 1800, 2000mm

Heating Power:	9kw-15kw
Air Pressure(Kg.F /Cm2):	6.0-8.0
Bending Length:	2000-6000mm
Warranty Time:	One Year
Sheet Thickness:	3.0-30.0mm
Rated VoltageRated Voltage:	380V50/60Hz
Processing Period:	20 Days
Specification:	Sheet Width 600, 900, 1200, 1500, 1800, 2000mm

Product Description

Length 3000mm PVC Sheet Welding Machine HDPE Welding Bending Machine

Key Features

Handles plastic boards from 3000mm to 6000mm length and 3mm to 30mm thickness
Horizontal and round (rolling) weld capabilities (minimum 500mm circular size)
Bends plastic plates from 2 to 100 degrees
Suitable for PP, PE, HDPE, PVDF, PVC, PPN thermoplastic sheets
24-month machine quality guarantee

Technical Specifications

Heating Power 9kw-15kw

Air Pressure 6.0-8.0 Kg.F/Cm²

Bending Length 2000-6000mm

Sheet Thickness 3.0-30.0mm

Voltage 380V 50/60Hz

Sheet Width Options 600, 900, 1200, 1500, 1800, 2000mm

Model Comparison

Parameter	SIN-3000	SIN-4000
Processing thickness (mm)	3-30mm	3-30mm
Processing length (mm)	3000	4000
Bending angle	0-135	0-135
Air pressure (kg.f/cm²)	4-10	4-10
Energy source (m³/min)	0.0032	0.0052
Rated voltage (V)	380	380
Dimensions (L×W×H mm)	4200×1900×1600	5200×2900×1600

Applications

Reservoirs, tanks, and containers manufacturing
Plastic apparatus production
Pipeline construction and ventilation systems
Serial welding and water treatment systems
Scrubbers, environmental technology, swimming pools
Transport and logistics applications

Support & Services

Our technical support team provides installation assistance, troubleshooting guidance, and maintenance recommendations to ensure optimal equipment performance.

Packaging & Shipping

The equipment is securely packaged with stretch film and wooden pallets to prevent damage during transportation. We offer fast shipping with tracking information provided.

Frequently Asked Questions

What is the brand name of this equipment?

Sincere

What models are available?

SMH-3000, SMH-4000, and SMH-5000

Where is this equipment manufactured?

China

What certifications does it have?

CE certified

What is the minimum order quantity?

1 unit

What is the delivery time?

15 working days

What is the monthly production capacity?

20 sets per month
