HDPE COD Spiral Protector Pipe Extrusion Lines PE Pipe Extrusion Machine

Name: HDPE COD Spiral Protector Pipe Extrusion Lines PE Pipe Extrusion Machine
Brand: Qingdao Sincere Machinery Co., Ltd
SKU: SMSP-40
Price: 110.00 USD
Availability: InStock

Product Details

Brand Name: SincereMachinery

Model Number: SMSP-40

Payment & Shipping Terms

Price: USD 20,000-200,000

Get Best Price

Chat Now

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                COD Spiral Protector Pipe Extrusion Lines, HDPE Spiral Protector Pipe Extrusion Lines, Spiral PE Pipe Extrusion Machine


Product:	PE PP Spiral Guard Hose	Voltage:	380V Or Customized
Other Name:	PP PE Spiral Guard Protector Hose Making Machine	Motor Power:	37-55kw
Cooling Method:	Air Cooling Or Water Cooling	Main Motor Power:	37kw-110kw
Temperature Control:	Omron	Screen Brand:	Simens

Product:	PE PP Spiral Guard Hose
Voltage:	380V Or Customized
Other Name:	PP PE Spiral Guard Protector Hose Making Machine
Motor Power:	37-55kw
Cooling Method:	Air Cooling Or Water Cooling
Main Motor Power:	37kw-110kw
Temperature Control:	Omron
Screen Brand:	Simens

Product Description

HDPE COD Spiral Protector Pipe Extrusion Lines PE Pipe Extrusion Machine

Product Specifications

Attribute	Value
Product	PE PP Spiral Guard Hose
Voltage	380V Or Customized
Other Name	PP PE Spiral Guard Protector Hose Making Machine
Motor Power	37-55kw
Cooling Method	Air Cooling Or Water Cooling
Main Motor Power	37kw-110kw
Temperature Control	Omron
Screen Brand	Simens

Product Overview

The HDPE COD Spiral Protector Pipe Extrusion Line is a high-performance solution for producing PP/PE spiral protective sheath tubes. This advanced machinery features a specially designed sizing cooling method with a production range of 40mm to 300mm and speeds up to 0.6-1.5 meters per minute.

Key Features

Spiral distribution type fluid separation for optimal melt flow
Low melting temperature design for reduced internal stress
Smooth inner and outer pipe surfaces
Flexible co-extrusion capability for polyolefin materials
Optimized copper spiral sizing sleeve with pre-cooling device
Powerful vacuum suction for high-speed extrusion
Stainless steel equipment casing
Efficient spray cooling system
Three-dimensional adjustment capability

Production Line Components

The complete machine line consists of the following high-performance units:

SJ-45/33 single screw extruder and die head
Rotating forming machine
Hauling off machine
Circulating-water cooling tank
Meter counter
Winder

The units feature a compact structure with optimized screw and barrel design made of 38CrMoAiA material, ensuring uniform plasticizing, stable capacity, high output, and long service life.

Technical Parameters

Power	Screw	L/D	Output (kg)
3-4kw	21.7mm	32-60/1	2-15
11-30KW	35.6mm	32-60/1	10-40
45-90KW	50.5mm	32-60/1	120-20
75-160kw	62.4mm	32-60/1	255-400
110-250kw	71mm	32-60/1	450-750
250-550kw	93mm	32-60/1	950-1600

Applications

This spiral pipe extrusion line is ideal for construction projects requiring enhanced bearing capacity. The technology is particularly suited for:

Concrete pile foundations reinforcement
Beam and column strengthening
Large infrastructure projects (bridges, high-rise buildings)
Tunnel and reservoir construction
Coastal and chemical plant applications

Compared to traditional metal pipes, these HDPE spiral pipes offer superior corrosion resistance, making them ideal for humid, acidic, and alkaline environments.

Support & Services

Our comprehensive technical support package includes:

On-site installation and commissioning assistance
Operator and maintenance personnel training
Troubleshooting and remote technical support
Spare parts and components supply
Equipment upgrades and customizations
Regular maintenance programs

Packaging & Shipping

Each Spiral Pipe Extrusion Line component is securely wrapped and placed in sturdy wooden crates to prevent transit damage. Crates include clear handling instructions and product details.

We partner with trusted logistics providers to ensure timely delivery, providing tracking information for shipment monitoring.

Frequently Asked Questions

Q: What is the brand name of the Spiral Pipe Extrusion Line?

A: The brand name is SincereMachinery.

Q: What is the model number?

A: The model number is SMSP-40.

Q: What is the maximum pipe diameter?

A: The line can produce pipes with a maximum diameter of 40mm.

Q: Does it include a cooling system?

A: Yes, the SMSP-40 model has a built-in cooling system.

Q: Can it process HDPE materials?

A: Yes, it can process various materials including HDPE.
